Nevada 29 1.7

$749.99
Size Guide
Size
Color: Satin Gray

A staple in the Fuji mountain-bike lineup, available in 29" or 27.5" wheel sizes, the Nevada combines a tried and true hardtail frame and solid components to take your off-road adventures to the next level.


Technical Specifications
  • Sizes

    S, M, L, XL, XXL

    Color(s)

    Satin Gray, Cyan

    Frame

    Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle

    Fork

    SR Suntour SF19-XCT30-HLO-DS-29, hydraulic lockout, 100mm

    Crankset

    Prowheel, 42/34/24T

    Bottom Bracket

    Sealed cartridge bearing

    Pedals

    Resin platform

    Front Derailleur

    Shimano Tourney

    Rear Derailleur

    Shimano Acera

    Shifters

    Shimano Altus, Rapid Fire, 3 x 8-speed

    Cassette

    Shimano HG31, 11-34T

  • Chain

    KMC HV700

    Wheelset

    WTB SX19 rims 32H, Formula DC-20 front, DC-22 rear hubs, black spokes

    Tires

    WTB Ranger Comp, 29" x 2.25", 27tpi

    Brakeset

    Tektro HD-M275, 180/160mm rotors

    Brake Levers

    Tektro HD-M275

    Headset

    1 1/8" sealed bearings

    Handlebar

    Fuji flat bar, alloy, 710mm

    Stem

    Fuji, forged aluminum, +/-6¬į

    Grips

    Fuji Performance Grip

    Saddle

    Fuji Performance Saddle

    Seat post

    Fuji, alloy, 30.9mm

    Weight

    14.93 kg / 32.92 lbs

*Specifications are subject to change without notice
Geometry
Size S M L XL XXL
Bike Size 15" 17" 19" 21" 23"
A Seat Tube, Center To Top 370 420 470 520 560
C Top Tube, Effective 591 611 636 653 672
D Head Tube Length 95 105 110 120 130
E Seat Tube Angle 73¬į 73¬į 73¬į 73¬į 73¬į
G Head Tube Angle 69¬į 69¬į 69¬į 69¬į 69¬į
H Chainstay Length 450 450 450 450 450
I Wheelbase 1113.5 1134 1160 1177.5 1197
J Bottom Bracket Drop 55 55 55 55 55
K Fork Offset 46 46 46 46 46
M Stack 611.5 621 625.5 635 644
N Reach 404 421 445 459 475
O Standover 781 809 834.5 862 886
