Jari Carbon CX

$3,699.99 USD
Size Guide
Size
Color: Eggplant
Description
The Jari Carbon CX is anything but a one-trick pony - this bike shines on the cross course but is ready to take on a gravel race or go off on an adventure at a whim. With lively handling, obstacle-clearing BB height, and massive tire clearance you'll experience the agility and versatility many of today's gravel bikes are lacking. Punchy and quick while stable and comfortable at the same time, the Jari Carbon CX is the perfect weapon for race day, mixed terrain, gravel endurance rides, and getting out and exploring.
Shipping and Returns

SHIPPING

All non-bike items and a limited number of bike models have the option to ship to home. All other bikes ordered online will be delivered to your chosen local authorized Fuji dealer.

SHIP TO HOME RETURNS

Item(s) in new, unassembled, unused condition and with all original packaging, hangtags, and parts will be eligible for a refund when returned within 30 days of purchase. Return shipping fees apply.

*More Details

SHIP TO STORE RETURNS

Bicycles can be returned at time of pick-up only. After leaving the store with your assembled bicycle the sale is final. It’s up to the seller you purchased from to initiate the return. Restocking fee may apply.

*More Details

Technical Specifications
  • Sizes

    XS (49cm), S (52cm), M (54cm), L (56cm), XL (58cm), XXL (61cm)

    Color(s)

    Eggplant

    Frame

    C15 ultra high-modulus schedule process. High compaction molding. Micro-suspension rear triangle. English threaded BB, 142x12 thru-axle.

    Fork

    C15 ultra high-modulus schedule process, tapered steerer, 100x12mm thru-axle

    Crankset

    SRAM RIVAL 1X12 40T DUB

    Bottom Bracket

    SRAM DUB English threaded

    Rear Derailleur

    SRAM Rival AXS 1x12

    Shifters

    SRAM Rival AXS Hydraulic

    Cassette

    SRAM XG1250 10-36 12spd

    Chain

    SRAM Rival 12spd

  • Wheelset

    Oval Concepts 524 Disc, 24/28H, 21mm internal width

    Tires

    Vittoria Mezcal, G2.0, 700 x 35c

    Tubes

    700 x 35 presta

    Brakeset

    SRAM Hydraulic FM, 160mm rotor

    Brake Levers

    SRAM Rival AXS Hydraulic

    Headset

    FSA, 1 1/8” upper - 1 1/2” lower, integrated

    Handlebar

    Oval Concepts 310 Ergo, 6061 alloy, 31.8mm clamp, 133mm drop, 4° sweep

    Stem

    Oval Concepts 313, 3D-forged 6061, +/-6°

    Tape

    Selle Italia Smootape Corsa

    Saddle

    Selle Italia X-LR Air Cross Light

    Seatpost

    Oval Concepts 300, alloy, 27.2mm

*Specifications are subject to change without notice
Geometry
Size XS S M L XL XXL
A Seat Tube Center To Top 490 520 540 560 580 610
B Seat Tube Effective 562 583 598 619 639 659
C Top Tube Effective 525 535 545 560 575 590
D Head Tube Length 120 140 150 170 190 210
E Seat Tube Angle 74.5° 74° 73° 73° 72.5° 72.5°
G Headtube Angle 70.5 71 71.5 72 72 72
H Chainstay Length 435 435 435 435 435 435
I Wheelbase 1020 1022 1016 1027 1037 1058
J Bottom Bracket Drop 69 67 67 67 65 65
K Fork Offset 48 48 48 48 48 48
L Trail 73 70 67 64 64 64
M Stack 541 560 572 592 609 628
N Reach 375 374 370 379 383 397
O Standover 767 790 804 824 841 865
Stem 80 90 90 100 110 110
Handlebar Width 380 400 420 420 440 460
Crank 165 170 172.5 172.5 172.5 175
Wheel Size 700 700 700 700 700 700
Seat Post Diameter 27.2 27.2 27.2 27.2 27.2 27.2
