COVID-related supply issues have caused some bike specifications to differ from what is listed. Please check with your local Fuji dealer for the most up to date specifications on the bikes they have in their stores.
Fuji's mid-level aluminum and most widely used frame material which has a double butted profile in the frame tubes that reduces material in low stress areas and creates a lightweight frame that is extremely durable.
Thru-axles slide through a closed dropout increasing wheel security and the overall lateral stiffness of a frame creating a bike that has precise steering and optimal control.
Threaded bottom brackets are easy to replace and are significantly quieter than press fit.
Internal cable routing provides smooth shifting and a clean aesthetic.
S, M, L, XL
Fuji A2-SL custom-butted alloy front and rear triangle, 197x12mm dropout
Alloy rigid, tapered alloy steerer, 150x15mm
SRAM X1 Eagle, 30T
SRAM DUB, threaded
SRAM NX Eagle
SRAM SX Eagle, 1 x 12-speed
SRAM PG-1210, 11-50T
SRAM SX Eagle
Sun Ringle Mulefut 80mm 32H rims, Formula DC-150 front, DHL-197 rear hub, black stainless spokes
Maxxis Minion FBF, Minion FBR, 26" x 4.80", 120tpi, EXO, Tubeless Ready, folding
Shimano MT200, 180mm rotors OR C-STAR Rush
Shimano MT201 OR C-STAR Rush
FSA 1 1/8" - 1.5", sealed bearings
Fuji riser bar, alloy, 15mm rise, 760mm
Fuji, alloy, 0°
WTB Waffel Lock on
WTB Volt Sport
Fuji, alloy, 30.9mm
|A||Seat Tube, Center To Top||381||432||475||520|
|C||Top Tube, Effective||585||610||630||655|
|D||Head Tube Length||100||110||120||135|
|E||Seat Tube Angle||73.5°||73.5°||73.5°||73.5°|
|G||Head Tube Angle||69°||69°||69°||69°|
|J||Bottom Bracket Drop||58||58||58||58|
|Seat Post Diameter||30.9||30.9||30.9||30.9|
|5'11" - 6'2"||180cm - 188cm|
*Suggested sizes shown. For the most accurate sizing please visit your local authorized Fuji retailer for a bike fit and a test ride.
