The Rakan might be the most efficient pedaling trail bike on the market, with 120mm of MLink® Suspension Design technology, modern geometry and 29-inch wheels make it the obvious choice if you're looking for a do-it-all mountain bike.
S, M, L, XL
Matte Beige
Fuji A6-SL super-butted alloy front and rear triangle, Enduro Max sealed cartridge bearings, MLink patented suspension system, Boost 148x12mm, UDH, 120mm
RockShox Pike Select 29 DebonAir, tapered alloy steerer, Boost 110x15mm, 44mm offset, 140mm
RockShox Deluxe Select+ RL
Truvativ Descendant, 32T
SRAM DUB, threaded
SRAM GX Eagle
SRAM GX Eagle, 1 x 12-speed
SRAM XG-1275, 10-52T
SRAM GX Eagle
WTB Speedterra ST i30 TCS 2.0 wheelset, 32H
Maxxis Minion DHF, 29" x 2.50" WT, 3C Maxx Terra, 60tpi, EXO, Tubeless Ready, folding, Maxxis Dissector, 29" x 2.40" WT, 3C Maxx Terra, 60tpi, EXO, Tubeless Ready, folding
SRAM G2 R, 180mm rotors
SRAM G2 R
FSA 1 1/8" - 1.5", sealed cartridge bearings
Race Face Aeffect R Riser Bar, alloy, 20mm rise, 780mm
Race Face Aeffect R, alloy, +0° rise
Ergon GA20, Lock on
Fizik Alpaca Terra X5
Crankbrothers Highline 3 dropper, 31.6mm, 15" - 125mm travel, 17, 19"- 150mm travel, 21" - 170mm travel, Highline Premium Ball Socket Lever
MRP 1X Chainguide
TBD
| Size | S | M | L | XL | |
|---|---|---|---|---|---|
| Bike Size | 15" | 17" | 19" | 21" | |
| A | Seat Tube, Center To Top | 380 | 420 | 458 | 495 |
| C | Top Tube, Effective | 590 | 618 | 646 | 668.5 |
| D | Head Tube Length | 100 | 110 | 120 | 130 |
| E | Seat Tube Angle | 77° | 76.5° | 76° | 76° |
| G | Head Tube Angle | 65° | 65° | 65° | 65° |
| H | Chainstay Length | 431 | 431 | 431 | 431 |
| I | Wheelbase | 1194.9 | 1219 | 1243.3 | 1267.5 |
| J | Bottom Bracket Drop | 32 | 32 | 32 | 32 |
| K | Fork Offset | 42 | 42 | 42 | 42 |
| M | Stack | 607.9 | 616.9 | 626 | 635 |
| N | Reach | 450 | 470 | 490 | 510 |
| O | Standover | 748.3 | 766.5 | 762.4 | 783 |
| Stem | 40 | 40 | 40 | 40 | |
| Handlebar Width | 780 | 780 | 780 | 780 | |
| Crank | 170 | 170 | 170 | 170 | |
| Wheel Size | 29" | 29" | 29" | 29" | |
| Seat Post Diameter | 31.6 | 31.6 | 31.6 | 31.6 |
